PS4 Boat Switch
2. Can withstand high current and surge current.
3. Widely used in televisions, audio devices, computers and peripheral equipment.
所属分类：
PS4 Power Switch
关键词： PS4 Boat Switch
产品附件：
在线留言
- Description
- Product Parameters
- Video
-
- Commodity name: PS4 Boat Switch
1. It has the characteristics of fast action.<br>2. Can withstand high current and surge current.<br>3. Widely used in televisions, audio devices, computers and peripheral equipment.
PS4 Power Switch High Temperature Resistance Quick Action Spring Button
1.Product Introduction
The characteristics of PS4 power switch are high temperature resistance and quick action. Outside spring type and inside spring type are optional. We are a manufacturer of micro switches, waterproof switches,power switches. Please kindly contact us if you need any further information.2.Product Parameter
Item
Value
Environment temperature
-10~+85°C, 0~125°C
Relative humidity
95%,40°C
Ratings
TV-5 125VAC , 10GPA125/250VAC , 10A125/250VAC
8A/128A250VACOperating travel/full
2.5mm/3.5mm
Operating force
2N~6N
Circuit
SPST
Insulation resistance
≥100MΩ
Contact resistance
≤ 50mΩ
(Test voltage) Between each terminals of the same polarity
AC2000V
(Test voltage) Between current-carrying metal parts and ground(case), and between each terminal and non-current-carrying metal parts
AC4000V
Electrical Life
10,000 cycles
Weight
Approx . 7.8g
Sofety approavals
UL , CUL , VDE , ENEC , TUV,SEMKO , DEMKO , NEMKO , FIMKO ,CE , EK , CQC
3.Product Feature and Application
One of the outstanding features of the PS4 micro power switch is its ability to withstand high currents. This means that you can confidently use it to power your devices. In addition, its compact size makes it very easy to install in any environment.
Our PS4 power switches are not only durable, they are also made from high temperature resistant materials. This ensures longevity and reliability, even in harsh environments.
Key words:- PS4
- 电源开关，自锁，东南电子
-
