Rotary Switches KXZ2

1. There are multiple gears and multiple shift rotation angles.
2. Can be automatically reset.
3. Used for household appliances such as material presses.

所属分类:

KXZ2 Rotary Switch

关键词: Rotary Switches KXZ2

产品附件:


在线留言
  • Description
  • Product Parameters
  • Video
    • Commodity name: Rotary Switches KXZ2

    1. There are multiple gears and multiple shift rotation angles.<br>2. Can be automatically reset.<br>3. Used for household appliances such as material presses.

    KXZ2 Rotary Switch Automatic Resettable Function with Various gears and UL Certificate



    1.Product Introduction
    The KXZ2 rotary switch has an automatic reset function for added convenience. There are various gears like 45,36 and 30. We are a switch factory and our products have many patents and certificates to meet different market demands. If you are looking to become our professional partner, please contact us.



    2.Product Parameter

    Item

    Value

    Environment temperature

    -25~+105ºC

    Relative humidity

    90% , 40ºC

    Rated current/voltage

    8GPA 125VAC , 6(3)A250VAC

    Rotary angle

    45°/place ; 36°/place ; 30°/place

    Insulation resistance

    ≥100MΩ(DC500V)

    Contact resistance

    ≤30mΩ

    (Test voltage)  Terminal-terminal

    AC1500V

    (Test voltage)  Terminal-case

    AC1500V

    Electrical life

    10,000 cycles

    Weight

    Approx . 11.5g

    Safety approvals

    UL , CUL,ENEC,DEMKO,CQC



    3.Product Feature and Application
    The KXZ2 rotary switch is a high quality switch for household appliances. The switch has multi-gear and multi-position rotation angle, which can meet the different needs of various household appliances. In addition, the KXZ2 rotary switch has an automatic reset function, which is convenient for users. The switch is widely used in cooking machines and other household appliances, which can help users easily achieve various operations and improve the quality of life.
