WS5 automotive waterproof micro switch

1. Small body shape and compact structure; long stroke, dustproof and waterproof.
2, complete terminal types, can be equipped with a variety of wires.
3, equipped with various forms of boom.
4, can be used in automobiles, household appliances, industrial control equipment and other occasions with environmental performance requirements and outdoor equipment and instruments.

Category:

WS5 Waterproof Switch

Keyword: WS5 automotive waterproof micro switch

Accessories:


Message
  • Description
  • Product Parameters
  • Video
    • Commodity name: WS5 automotive waterproof micro switch

    1. Small body shape and compact structure; long stroke, dustproof and waterproof.<br>2, complete terminal types, can be equipped with a variety of wires.<br>3, equipped with various forms of boom.<br>4, can be used in automobiles, household appliances, industrial control equipment and other occasions with environmental performance requirements and outdoor equipment and instruments.

    WS5 Waterproof Switch Dustproof Long Travel Can be Used in Frequnt Vibration Environment

    1.Product Introduction
    WS5 waterproof micro switch is dustproof and has 2mm long stock. It has a strong anti-vibration ability which can be use in frequent vibration enviroment. We are a professional waterproof switch manufacturer can be tailored to your specific needs, welcome to visit us.



    2.Product Parameter

    Item

    Value

    Operating speed

    0.1mm~1mm/s (no lever)

    Operating frequency

    Mechanical 60 cycles/min; electrical 25 cycles/min

    Insulation resistance

     ≥100MΩ(500VDC)

    Contact resistance

     Terminal type ≤ 50mΩ
    Wire type≤ 100mΩ(24#,L≤ 200mm)

    (Test voltage) Between non-continuous terminals

    AC500V , 50/60Hz , 1min

    (Test voltage) Between each terminal and other exposed metal parts
    Between each terminal and ground

    AC1500V , 50/60Hz , 1min

    Vibration resistance

    10~55Hz , 1.5mm Double  amplitude

    Shock resistance

    endurance:1000m/s2(approx.100G)max
     Wrong action:300m/s2(approx.30G)max

    Electric shock proof protection grade

    I class

    Case protection degree

     IEC IP67(Besides terminal part of terminal type) Or other grades

    Life

    Mechanical  ≥ 500,000 cycles
    Electrical ≥ 100,000 cycles

    Safety approvals

    UL/CUL ,TUV,CE ,CQC



    3.Product Feature and Application
    The WS5 waterproof micro switch is a specialized switch for use in frequently vibrating environments, such as industrial control equipment. Its compact size, strong dustproof performance and long travelling characteristics enable stable operation in complex working environments. In addition, the WS5 waterproof smicro witch is equipped with various levers and contact terminals for easy installation and wiring. Whether in industrial equipment or other fields, it can be easily applied.
