MS3 microswitch

1. With protection function.
2. Can be used on drainage pumps and similar equipment.

所属分类:

MS3 Micro Switch

关键词: MS3 microswitch

产品附件:


在线留言
  • Description
  • Product Parameters
  • Video
    • Commodity name: MS3 microswitch

    1. With protection function.<br>2. Can be used on drainage pumps and similar equipment.

    MS3 Micro Switch with Safest On-Off Structure Customized for Water Lever Control


    1.Product Introduction
    MS3 micro switch features the safest on-off structure. A break in either contact ends the operation. The custom-made micro switches is made for water level control. We can provide a wide range of high-quality micro switches for various industries. If any queations, please do not hesitate to contact us.



    2.Product Parameter

    Item

    Value

    Operating speed

    0.1mm~1m/s (No lever)

    Operating frequency

    Mechanical 60 cycles/min; electrical 25 cycles/min

    Insulation resistance

    ≥ 100MΩ(500VDC)

    Contact resistance

    ≤50mΩ

    (Test voltage) Between not connect terminals of the same polarity

    AC1000V , 50/60Hz , 1min

    (Test voltage) Between current-carrying metal parts and Ground(case), and between each terminal and non-current-carrying  metal  parts.

    AC2000V , 50/60Hz , 1min

    Vibration resistance

    10~55Hz , 1.5mm Double  amplitude

    Shock resistance

    Endurance:1000m/s2(approx.100G)max
    Wrong action:300m/s2(approx.30G)max

    Electric shock proof protection degree

    II class

    Life

    Mechanical ≥ 500,000 cycles
    Electrical ≥ 50,000 cycles

    Safety approvals

    UL,CUL,,ENEC, DEMKO,EK, CQC



    3.Product Feature and Application
    The MS3 micro switch on off is a highly reliable switch with protection. It is customised for controlling drainage pumps and other similar equipment with high reliability and durability.One of the main advantages of the micro limit switch is its long life reliability. It is durable and can be operated for long periods of time without any problems. This makes it a popular choice for many customers.
