KW4A household appliances gas stove micro switch 10A125V

Product list

Number of views:
1345

KW4A household appliances gas stove micro switch 10A125V

1.Nice appearance,tight configuration.Characteristic:small contact gap,quick action,high sensiticity and small operaing travel. reliability.
Retail price
0.0
Market price
0.0
Number of views:
1345
Product serial number
Quantity
-
+
Stock:
Product description
Parameters
Detail

Safe,reliable miniature switch
Nice appearance,tight configuration.Characteristic:small contact gap,quick action, high sensitivity and small operating travel.
Long life,high reliability.
A variety of contact terminals
A variety of levers
Adopt thermosetting plastic or thermoplastic case.
Widely used in home appliance,electronic equipment,automatic machine,communication equipment,car electron,apparatus and instrument etc.

Technical Characteristics

Item                                    Value
Operating speed 0.1mm-1m/s(Related with actuator forms)
Operating frequency  Mechanical 60 cycles/min; electrical 25 cycles/min
Insulation resistance ≥100mΩ(500VDC)
Contact resistance OF>0.5N:≤30mΩ(see note)
OF≤0.5N : ≤50mΩ(see note)
(Test voltage) Between terminals of the same polarity AC1000V , 50/60Hz , 1min
(Test voltage) Between current-carrying metal parts and  AC1500V , 50/60Hz , 1min
ground (case),and between each terminal and non-current-carrying metal parts
Vibration resistance 10-55Hz , 1.5mm Double amplitude
Shock resistance Destruction : OF>0.5N: 1000m/s2(approx.100G)max
OF≤0.5N: 500m/s2(approx.50G)max
Malfunction : OF>0.5N: 300m/s2(approx.30G)max
OF≤0.5N: 200m/s2(approx.20G)max
Life Mechanical ≥ 1,000,000 cycles
Electrical≥10,000 cycles
Weight Approx.1.6g(No lever)
Safety approvals UL ,CUL ,VDE, TUV, ENEC,  DEMKO, CE ,EK CQC
