- Commodity name: MS9 microswitch
1.MS9 micro switch adopts dust-proof design, and the upper and lower structures are seamless and dust-proof<br>2. Compact structure, high sensitivity for fast action<br>3. Equal foot spacing of terminals can avoid frequent on-off state of contact points during vibration. Can be used in household appliances, power tools, toys, fax machines, alarms and other fields. Various types of boom
MS9 Micro Switch Dust-proof Type Wholesale Price for Power Tools and Alarms
1.Product Introduction
MS9 micro switch is dust-proof type with wholesale micro switch price. It can be used in powertools and alarms. We specialize in the development, production, and sales of electronic switches such as micro switches and waterproof micro switches. Welcome to order our products.
2.Product Parameter
Item
Value
Environment temperature
-40~+125ºC
Operating speed
30mm-600mm/s(No lever)
Operating Frequency
Mechanical 60 cycle/min; Electrical 25 cycles/min
Insulation resistance
≥ 100MΩ(500VDC)
Contact resistance
≤50mΩ
(Test voltage) Between terminals of the same polarity
AC1000V,50/60Hz,1min
(Test voltage) Between current-carrying metal parts and ground (case),and between each terminal and non-cueeent-carrying metal parts.
AC1500V,50/60Hz,1min
Vibration resistance
10-55Hz,1.5mm Double amplitude
Shock resistance
endurance:1000m/s2(approx.100G)max
Wrong action:300m/s2(30 G approx.30G)maxDegree protection provided by enclosure
IEC IP40
Electrical life
≥10.000cycles or ≥50.000cycles
Mechanical life
≥1000.000cycles
3.Product Feature and Application
As a high-performance switch, the MS9 electronic micro switch has an upper and lower cover structure, which effectively prevents dust from entering the inside of the switch, improves the stability and reliability of the switch, and prolongs the service life of the product. This feature makes the MS9 professional micro switch widely used in household appliances, power tools and toys. In addition, the point cntact is stable and reliable.
-
