MS12 microswitch

MS12 micro switch is small in size, the base and terminal are integrally formed
spring type structure, small gap and high sensitivity

Category:

MS12 Micro Switch

Keyword: MS12 microswitch

Accessories:


Message
  • Description
  • Product Parameters
  • Video
    • Commodity name: MS12 microswitch

    MS12 micro switch is small in size, the base and terminal are integrally formed<br>spring type structure, small gap and high sensitivity

    MS12 Micro Switch Small Contat Gap High Sensitivity with Sharpnet Structure



    1.Product Introduction
    MS12 micro switch is super small size with good electrical performance. It is small contact gap and high sensitivity because of sharpnet structure. Dongnan switch factory has a complete production system and an excellent production team for making micro switch. If you are interested in our micro switch products and want to know more product information, please contact us immediately.



    2.Product Parameter

    Item

    Value

    Operating speed

    0.1mm-0.5mm/s(No lever)

    Operating Frequency

    Mechanical 60 cycle/min; Electrical 25 cycles/min

    Insulation resistance

    ≥ 100MΩ(500VDC)

    Contact resistance

    ≤100mΩ

    (Test voltage) Between terminals of the same polarity

    AC500V,50/60Hz,1min

    (Test voltage) Between current-carrying metal parts and ground (case),and between each terminal and non-cueeent-carrying metal parts.

    AC500V,50/60Hz,1min

    Vibration resistance

    10-55Hz,1.5mm Double amplitude

    Shock resistance

    endurance:200m/s2(approx.20G)max
    Wrong action:100m/s2(approx.10G)max

    Ambient operation humidity

    35% to 85% RH (for +5ºC to + 35)

    Case protection degree

    IEC IP40

    Life

    Mechanical ≥ 50,000 cycles
    Electrical≥30,000 cycles

    Weight

    Approx.0.3g(No lever)



    3.Product Feature and Application
    MS12 subminiature micro switch adopts the integrated structure of base and terminal, which makes the size more compact. It can help users save valuable space and improve the efficiency and performance of the equipment. The sharpnet type structure features small gap and high sensitivity. The safety micro switch is suitable for installation where space is limited, and can achieve efficient control in a small space.
