SS5 Coded Switches
Compact structure and small size;
Stable contact; SS5 coding switch is widely used in overclocking non-silk communication, radio and television equipment on computer motherboards
Category：
SS5 Toggle Switch
Keyword： SS5 Coded Switches
Accessories：
Message
- Description
- Product Parameters
- Video
-
- Commodity name: SS5 Coded Switches
Features and uses<br>Compact structure and small size;<br>Stable contact; SS5 coding switch is widely used in overclocking non-silk communication, radio and television equipment on computer motherboards
SS5 Toggle Switch Small Vloume Stable Contact Customization for Wireless Communication
1.Product Introduction
SS5 toggle switch is our latest invension small vloume stable contact. specilized customized for wiress communicationWell known as a specialised switch manufacturer in China, we produce high quality toggle switch product. We willing to co-operate with you.2.Product Parameter
Item
Value
Environment temperature
-30~+85ºC
Operating speed
300mm~600mm/s
Operating Frequency
Mechanical 60cycles/min; Electrical 15 cycles/min
Insulation resistance
≥ 100MΩ(500VDC)
Contact resistance
≤ 50mΩ
(Test voltage) Between each terminals of the same Polarity.
AC300v , 50/60Hz , 1min
(Test voltage) Between current-cattying metal parts and ground(case), and between each terminal and non-current-carrying metal parts.
AC500v , 50/60Hz , 1min
Vibration resistance
10~55Hz , 1.5mm Double amplitude
Shock resistance
Endurance: 1000m/s(100Gapprox.10OG)max
Wrong action:300m/s(30Gapprox.30G)maxElectrical life
≥10,000 cycles
Mechanical life
≥10,000 cycles
3.Product Feature and Application
SS5 micro toggle switch is a compact structure, stable and reliable contact switch. SS5 micro toggle switch on off is widely used in radio and television and other equipments. The switches can ensure the normal operation of the equipment by the stable contact of the contacts.
-
