Electric Heater Waterproof Micro Switch Customized with UL ENEC 1Year Warranty
Category：
Solution
Home Appliance
Electric Heater
Keyword： Electric Heater Waterproof Micro Switch Customized with UL ENEC 1Year Warranty
Accessories：
Message
- Description
- Product Parameters
- Video
-
- Commodity name: Electric Heater Waterproof Micro Switch Customized with UL ENEC 1Year Warranty
3.Product Feature and Application of Electric Heater Waterproof Micro Switch The customized waterproof micro switch provides waterproof protection in electric heaters. As electric heaters generate high temperatures when in use and are often in wet environments, waterproof micro switches are needed to prevent moisture from penetrating into the switch and causing short circuits or other malfunctions. The special design of the waterproof microswitch can effectively prevent moisture from entering and ensure the normal operation of the heater.
Electric Heater Waterproof Micro Switch Customized with UL ENEC 1Year Warranty
1.Product Introduction of Electric Heater Waterproof Micro Switch
Electric heater waterproof micro switch is one of the is one of our hot waterproof switches.We have developed many types of waterproof switches lIke smallest size switch, explosion certificate waterproof switch,etc. If you need learn more information, you can contact us on the website.
2.Product Parameter of Electric Heater Waterproof Micro Switch
Item
Value
Operating speed
0.1mm~1m/s (no lever)
Operating frequency
Mechanical 60 cycles/min; electrical 25 cycles/min
Insulation resistance
≥100MΩ(500VDC)
Contact resistance
≤ 30mΩ(Initial value)
(Test voltage) Between not connect terminals of the same polarity
AC1000V , 50/60Hz , 1min
(Test voltage) Between current-carrying metal parts and ground (case),and between each terminal and non-cueeent-carrying metal parts.
AC1500V , 50/60Hz , 1min
Vibration resistance
10~55Hz , 1.5mm Double amplitude
Shock resistance
endurance : 1000m/s2(approx. 100G) max
Wrong action : 300m/s2 (approx. 30G) maxElectric shock proof protection grade
I class
Degree protection provided by enclosure
IEC IP67 (Besides terminal part of terminal type )
Life
Mechanical ≥ 1,000,000 cycles
Electrical ≥ 50,000 cyclesSafety approvals
UL ,CUL ,ENEC ,DEMKO,CE,CQC
3.Product Feature and Application of Electric Heater Waterproof Micro Switch
The customized waterproof micro switch provides waterproof protection in electric heaters. As electric heaters generate high temperatures when in use and are often in wet environments, waterproof micro switches are needed to prevent moisture from penetrating into the switch and causing short circuits or other malfunctions. The special design of the waterproof microswitch can effectively prevent moisture from entering and ensure the normal operation of the heater.
