Water Heater Rocker Switch AC1500V Various Optional Colors with UL TUV CE
Category：
Solution
Home Appliance
Water Heater
Keyword： Water Heater Rocker Switch AC1500V Various Optional Colors with UL TUV CE
Accessories：
Message
- Description
- Product Parameters
- Video
-
- Commodity name: Water Heater Rocker Switch AC1500V Various Optional Colors with UL TUV CE
3.Product Application of Water Heater Rocker Switch In a water heater, a rocker switch is usually installed at the bottom of the tank or water heater to monitor changes in the water level. When the water level in the water heater drops to a preset minimum level, the float sinks with it. This in turn triggers the action of the micro rocker switch, which automatically activates the heating unit to heat the water to the set temperature. And when the water level rises to the preset maximum level, the float will rise. The rocker switch will also trigger the action to cut off the circuit and stop the heating process to ensure the safe operation of the water heater.
Water Heater Rocker Switch AC1500V Various Optional Colors with UL TUV CE
1.Product Introduction of Water Heater Rocker Switch
Water heater rocker switch has various optional colors like red,black. It is AC1500V with UL TUV CE. We are a switch factory, and we produce not only micro switches but also rocker switches. If you need micro switches or rocker switches, you can contact us!
2.Product Parameter of Water Heater Rocker Switch
Item
Value
Operating Frequency
Mechanical 60cycles/min; Electrical 15 cycles/min
Insulation resistance
≥ 100MΩ(500VDC)
Contact resistance
≤ 30mΩ(Initial value)
(Test voltage) Between not connect terminals of the same Polarity.
AC1500v , 50/60Hz , 1min
(Test voltage) Between current-cattying metal parts and ground(case), and between each terminal and non-current-carrying metal parts.
AC1500v , 50/60Hz , 1min
Vibration resistance
10~55Hz , 1.5mm Double amplitude
Electrical life
50,000 cycles
Safety approvals
UL , CUL , TUV , SEMKO , CE , CQC
3.Product Application of Water Heater Rocker Switch
In a water heater, a rocker switch is usually installed at the bottom of the tank or water heater to monitor changes in the water level. When the water level in the water heater drops to a preset minimum level, the float sinks with it. This in turn triggers the action of the micro rocker switch, which automatically activates the heating unit to heat the water to the set temperature. And when the water level rises to the preset maximum level, the float will rise. The rocker switch will also trigger the action to cut off the circuit and stop the heating process to ensure the safe operation of the water heater.
