Blender Waterproof Switch Subminiature Size Anti-Dullness Design with Arc Lever
Category：
Solution
Home Appliance
Blender or Food Processer
Keyword： Blender Waterproof Switch Subminiature Size Anti-Dullness Design with Arc Lever
Accessories：
Message
- Description
- Product Parameters
- Video
-
- Commodity name: Blender Waterproof Switch Subminiature Size Anti-Dullness Design with Arc Lever
3.Product Application of Blender Waterproof Switch Waterproof function is very important for blender as they are appliances commonly used to process liquid food. This waterproof Micro Switch Arc Lever china adopts special sealing structure and materials that prevent water and other liquids from penetrating into the interior of the switch, thus protecting the safety and stability of the circuit. In this way, waterproof microswitches can work normally and will not be damaged by liquid erosion even if there is water splashing or liquid food overflow when the blender is in use.
Blender Waterproof Switch Subminiature Size Anti-Dullness Design with Arc Lever
1.Product Introduction of Blender Waterproof Switch
Blender waterproof switch is subminiature size with arc lever. The case is anti-dullness design. We devote ourselves for more than thirty years into the development and manufacture of waterproof switches. Kindly pick up our waterproof micro switch.
2.Product Parameter of Blender Waterproof Switch
Item
Value
Operating speed
1mm~500mm/s (no lever)
Operating frequency
Mechanical 60 cycles/min; electrical 25 cycles/min
Insulation resistance
≥100MΩ(500VDC)
Contact resistance
≤ 50mΩ(Without wire)
(Test voltage) Between non-continuous terminals
AC1000V , 50/60Hz , 1min
(Test voltage) Between each terminal and other exposed metal parts
Between each terminal and groundAC1500V , 50/60Hz , 1min
Vibration resistance
10~55Hz , 1.5mm Double amplitude
Shock resistance
Min:294m/s2(30G)
1ms Contact opening max. 1msec.Electric shock proof protection grade
I class
Case protection degree
IEC IP50(Terminal type)
IEC IP67(Wire leads type)Life
Mechanical ≥ 500,000 cycles
Electrical ≥ 50,000 cyclesSafety approvals
UL ,CUL ,ENEC ,DEMKO
3.Product Application of Blender Waterproof Switch
Waterproof function is very important for blender as they are appliances commonly used to process liquid food. This waterproof Micro Switch Arc Lever china adopts special sealing structure and materials that prevent water and other liquids from penetrating into the interior of the switch, thus protecting the safety and stability of the circuit. In this way, waterproof microswitches can work normally and will not be damaged by liquid erosion even if there is water splashing or liquid food overflow when the blender is in use.
