Center Control Lock Micro Switch Shock Resistance Anti-vibration 10A 12VDC
Category：
Solution
Auto Parts
Center Control Lock
Keyword： Center Control Lock Micro Switch Shock Resistance Anti-vibration 10A 12VDC
Accessories：
Message
- Description
- Product Parameters
- Video
-
- Commodity name: Center Control Lock Micro Switch Shock Resistance Anti-vibration 10A 12VDC
3.Product Feature and Application of Center Control Lock Micro Switch Shock Resistance The Shock Resistance Micro Switch is able to sense the opening and closing status of the door through the action of the sensor, thus realising remote control of the door. It can communicate the owner's operation signal to the central control lock, thus realising the remote opening and closing of the door, which improves the safety and convenience of the vehicle.
Center Control Lock Micro Switch Shock Resistance Anti-vibration 10A 12VDC
1.Product Introduction of Center Control Lock Micro Switch Shock Resistance
Center control lock micro switch has strong shock resistance and anti-vibration ability. Its maximum rated and voltahe is 10A 12VDC. We focus on producing high-quality Full stroke force micro switch for Auto Parts and work with many car brands. If you need auto microswitch, please contact us.
2.Product Parameter of Center Control Lock Micro Switch Shock Resistance
Item
Value
Environment temperature
-40~+85°C
Relative humidity
45%~85%,40°C
Rated current
3A/6A/10A
Rated voltage
DC12V
Operating force
≤4.5N
Operating speed
0.1mm~1m/s
Operating Frequency
Mechanical 60 cycle/min; Electrical 25 cycles/min
Insulation resistance
≥100MΩ(500VDC)
Contact resistance
≤50mΩ
(Test voltage) Between terminals of the same polarity
AC1000V,50/60Hz, 1min
(Test voltage) Between current-carrying metal parts and ground(case), and between each terminal and non-current-carrying metal parts.
AC2000V, 50/60Hz , 1min
Vibration resistance
10~55Hz , 1.5mm , double amplitude
Shock resistance
endurance: 1000m/s2(approx.100G)max
Wrong action :300m/s2(approx.30G)maxLife
Mechanical≥100,000 cycles
Electrical≥30,000 cycles3.Product Feature and Application of Center Control Lock Micro Switch Shock Resistance
The Shock Resistance Micro Switch is able to sense the opening and closing status of the door through the action of the sensor, thus realising remote control of the door. It can communicate the owner's operation signal to the central control lock, thus realising the remote opening and closing of the door, which improves the safety and convenience of the vehicle.
