Car Charging Gun Subminiature Waterproof Switch Snap Action Dirct Sell
Category：
Solution
Auto Parts
Car Door
Keyword： Car Charging Gun Subminiature Waterproof Switch Snap Action Dirct Sell
Accessories：
Message
- Description
- Product Parameters
- Video
-
- Commodity name: Car Charging Gun Subminiature Waterproof Switch Snap Action Dirct Sell
3.Product Feature and Application of Car Trunk Waterproof Micro Switch The waterproof mini micro switch controls the lights in the trunk of your car. When the trunk lid is closed, the switch will automatically break the circuit, making the trunk light go out to save electricity. When the trunk lid is open, the waterproof micro switch will automatically close the circuit, making the trunk light come on, making it easy for users to find things at night.
Car Charging Gun Subminiature Waterproof Switch Snap Action Dirct Sell
1.Product Introduction of Car Trunk Waterproof Micro Switch
Car trunk waterproof micro switch has extruded waterproof design for improved waterproof capacity. It can keep stable becaused of silver contact. We are automobile waterproof micro Switch producer with high quality and professional technology. If you need waterproof switch, please tell us.
2.Product Parameter of Car Trunk Waterproof Micro Switch
Item
Value
Operating speed
1mm~500mm/s (no lever)
Operating frequency
Mechanical 60 cycles/min; electrical 25 cycles/min
Insulation resistance
≥100MΩ(500VDC)
Contact resistance
≤ 50mΩ(Initial value)
(Test voltage) Between non-continuous terminals
AC600V , 50/60Hz , 1min
(Test voltage) Between each terminal and other exposed metal parts
Between each terminal and groundAC1500V , 50/60Hz , 1min
Vibration resistance
10~55Hz , 1.5mm Double amplitude
Shock resistance
Min:294m/s2(30G)
1ms Contact opening max. 1msec.Electric shock proof protection grade
I class
Case protection degree
IEC IP50(Terminal type)
IEC IP67(Wire leads type)Life
Mechanical ≥ 100,000 cycles
Electrical ≥ 10,000 cyclesSafety approvals
UL ,CUL ,ENEC ,DEMKO
3.Product Feature and Application of Car Trunk Waterproof Micro Switch
The waterproof mini micro switch controls the lights in the trunk of your car. When the trunk lid is closed, the switch will automatically break the circuit, making the trunk light go out to save electricity. When the trunk lid is open, the waterproof micro switch will automatically close the circuit, making the trunk light come on, making it easy for users to find things at night.
