Electric Drive Rods Micro Switch with Protection Function Dustproof Design
Category：
Solution
Low Voltage Electrical Equipments
Electric Drive Rods
Keyword： Electric Drive Rods Micro Switch with Protection Function Dustproof Design
Accessories：
Message
- Description
- Product Parameters
- Video
-
- Commodity name: Electric Drive Rods Micro Switch with Protection Function Dustproof Design
3.Product Feature and Application of Electric Drive Rods Micro Switch with Protection Function One of the functions of a microswitch is to protect the electric drive rod. It can signal when the electric drive rod reaches a specific position, triggering the system to stop or change the direction of operation in order to avoid damage to the electric drive rod by exceeding the limited range.
Electric Drive Rods Micro Switch with Protection Function Dustproof Design
1.Product Introduction of Electric Drive Rods Micro Switch with Protection Function
Electric drive rods micro switch has dustproof design that prevent dust from entering the gap between the cover and the base. It also has protection function. We make many types of microswitches for home appliances,low voltage eletcric equipments,etc. For your need of microswitches, please contact us.
2.Product Parameter of Electric Drive Rods Micro Switch with Protection Function
Item
Value
Operating speed
0.1mm~1m/s (No lever)
Operating frequency
Mechanical 60 cycles/min; electrical 25 cycles/min
Insulation resistance
≥ 100MΩ(500VDC)
Contact resistance
≤50mΩ
(Test voltage) Between terminals of the same polarity
AC1000V , 50/60Hz , 1min
(Test voltage) Between current-carrying metal parts and Ground(case), and between each terminal and non-current-carrying metal parts.
AC1500V , 50/60Hz , 1min
Vibration resistance
10~55Hz , 1.5mm Double amplitude
Shock resistance
Endurance:1000m/s2(approx.100G)max
Wrong action:300m/s2(approx.30G)maxElectric shock proof protection degree
II class
Case protection degree
IEC IP60 (specific specification)
Life
Mechanical ≥ 1,000,000 cycles
Electrical ≥ 50,000 cyclesSafety approvals
UL,CUL,,TUV,SEMKO,CE
3.Product Feature and Application of Electric Drive Rods Micro Switch with Protection Function
One of the functions of a microswitch is to protect the electric drive rod. It can signal when the electric drive rod reaches a specific position, triggering the system to stop or change the direction of operation in order to avoid damage to the electric drive rod by exceeding the limited range.
