Lightning Arrester Miniature Micro Switch Customization with Differential Strock
Category：
Solution
Low Voltage Electrical Equipments
Other low voltage electrical equipments
Keyword： Lightning Arrester Miniature Micro Switch Customization with Differential Strock
Accessories：
Message
- Description
- Product Parameters
- Video
-
- Commodity name: Lightning Arrester Miniature Micro Switch Customization with Differential Strock
3.Product Application of Lightning Arrester Miniature Micro Switch This Differential stroke micro switch which can be used to detect the working status of the lightning arrester. Through the microswitch, the closing and disconnecting status of the lightning arrester can be monitored in real time. Once the lightning arrester fails or is damaged, the micro switch will immediately send out a signal so that the lightning arrester can be repaired or replaced in time to ensure its normal operation.
Lightning Arrester Miniature Micro Switch Customization with Differential Strock
1.Product Introduction of Lightning Arrester Miniature Micro Switch
Lightning arrester miniature micro switch can customize differential strock according to requirements. We make micro switches related to low voltage electrical appliances. If there is a need, you can contact us.
2.Product Parameter of Lightning Arrester Miniature Micro Switch
Item
Value
Operating speed
0.1mm~1m/s (Related with actuator forms)
Operating frequency
Mechanical 60 cycles/min; electrical 25 cycles/min
Insulation resistance
≥ 100MΩ(500VDC)
Contact resistance
OF>0.5N:≤30m
OF≤0.5N:≤50mΩ (initial value)(Test voltage) Between terminals of the same polarity
AC1000V , 50/60Hz , 1min
(Test voltage) Between current-carrying metal parts and Ground(case), and between each terminal and non-current-carrying metal parts.
AC1500V , 50/60Hz , 1min
Vibration resistance
10~55Hz , 1.5mm Double amplitude
Shock resistance
Destruction:OF>0.5N:1000m/s2(approx.100G)max
OF≤0.5N:500m/s2(approx.50G)max
Malfunction:OF>0.5N:300m/s2(approx.30G)max
OF≤0.5N:200m/s2(approx.20G)maxWeight
Approx.1.6g(No lever)
Life
Mechanical ≥ 1,000,000 cycles
Electrical ≥ 10,000 cycles
Electrical ≥ 50,000 cycles(TUV, CQC)Safety approvals
UL,CUL,VDE,TUV,ENEC,SEMKO,DEMKO,CE,EK,CQC
3.Product Application of Lightning Arrester Miniature Micro Switch
This Differential stroke micro switch which can be used to detect the working status of the lightning arrester. Through the microswitch, the closing and disconnecting status of the lightning arrester can be monitored in real time. Once the lightning arrester fails or is damaged, the micro switch will immediately send out a signal so that the lightning arrester can be repaired or replaced in time to ensure its normal operation.
