Air Coditioner Mute Type Waterproof Switch IP67 Sealed Long Travel Customization
Category：
Solution
Home Appliance
Air Coditioner
Keyword： Air Coditioner Mute Type Waterproof Switch IP67 Sealed Long Travel Customization
Accessories：
Message
- Description
- Product Parameters
- Video
-
- Commodity name: Air Coditioner Mute Type Waterproof Switch IP67 Sealed Long Travel Customization
1.Product Introduction of Air Coditioner Mute Type Waterproof Switch Air coditioner custom waterproof switch is Sealed IP67 to prevent water and dust. It has mute type sliding contact and long travel. We make waterproof micro switch production and we have many dongnan switch agencies like Foshan,Ningbo,Shenzhen,etc. If you want to purchase waterproof switch, please communicate with us.
Air Coditioner Mute Type Waterproof Switch IP67 Sealed Long Travel Customization
1.Product Introduction of Air Coditioner Mute Type Waterproof Switch
Air coditioner custom waterproof switch is Sealed IP67 to prevent water and dust. It has mute type sliding contact and long travel. We make waterproof micro switch production and we have many dongnan switch agencies like Foshan,Ningbo,Shenzhen,etc. If you want to purchase waterproof switch, please communicate with us.
2.Product Parameter of Air Coditioner Mute Type Waterproof Switch
Item
Value
Environment temperature
-40~+85°C
Operating speed
30mm~600mm/s (no lever)
Operating frequency
Mechanical 60 cycles/min; electrical 25 cycles/min
Insulation resistance
≥100MΩ(500VDC)
Contact resistance
≤ 500mΩ
(Test voltage) Between non-continuous terminals
AC600V , 50/60Hz , 1min
(Test voltage) Between each terminal and other exposed metal parts
Between each terminal and groundAC1500V , 50/60Hz , 1min
Vibration resistance
10~55Hz , 1.5mm Double amplitude
Shock resistance
endurance:1000m/s2(approx.100G)max
Wrong action:300m/s2(approx.30G)maxElectric shock proof protection grade
I class
Case protection degree
IEC IP67(Besides terminal part of terminal type) Or other grades
Electrical Life
≥ 500,000 cycles(1mADC5V,50mADC16V)
≥ 200,000 cycles(50mADC 30V)3.Product Feature and Application of Air Coditioner Mute Type Waterproof Switch
Custom waterproof micro switch can make different levers forms according to equipments. The switch is compact in size and is suitable for air conditioner where space is limited. This explosion proof micro switch can be safer in the event of a short circuit and will not cause a fire.
